Intercooled Turbocharging

What’s the Benefit?

This feature helps provide highly satisfying acceleration and enhanced fuel efficiency.

The Feature:

Turbocharging increases the efficiency of an engine, both in terms of fuel use and power production.

• In basic terms, a turbine wheel placed within the exhaust system is spun by the flow of exhaust gases.
• That turbine drives a shaft that in turn spins an air pump in the intake tract.
• The resulting increase in pressure pushes more air and fuel into the engine’s combustion chamber for a more powerful expansion of the ignited air-fuel mixture and greater power production.
• So, a smaller, more fuel-efficient engine can produce the torque of a bigger powerplant.
• An intercooler is placed within the intake tract to enhance the system’s efficiency even further.
  • The act of compressing the air heats it, creating a lower density of oxygen molecules necessary for combustion
  • When the heated air flows through the intercooler, its temperature is reduced and a more dense concentration of oxygen is then available for burning.
• It’s possible for a turbo system to create too much boost pressure on the intake side, destabilizing combustion and creating detonation, an uncontrolled burning of the air-fuel mixture.
  • To prevent this, a sensor in the intake side can trigger a device called a wastegate in the exhaust system.
  • When opened, the wastegate allows some of the exhaust flow to bypass the turbine, reducing its speed and resulting in lower intake-tract compression.
